RKL10BD103J の詳細情報

型番	RKL10BD103J
メーカー	KOA
データシート
Construction	Rectangular
Element Power Dissipation	0.125 W
First Element Resistance	10000 ohm
JESD-609 Code	e1
Lead Length	3.3 mm
Mounting Feature	THROUGH HOLE MOUNT
Network Type	BUSSED
Number of Elements	10
Number of Functions	1
Number of Terminals	11
Operating Temperature-Max	155 Cel
Operating Temperature-Min	-55 Cel
Package Height	5.08 mm
Package Length	27.94 mm
Package Shape	RECTANGULAR PACKAGE
Package Style	SIP Meter
Package Width	2.5 mm
Packing Method	BULK
Rated Temperature	70 Cel
Resistance	10000 ohm
Resistor Type	ARRAY/NETWORK RESISTOR
Second/Last Element Resistance	10000 ohm
Sub Category	ARRAY/NETWORK RESISTOR
Technology	METAL GLAZE/THICK FILM
Temperature Coefficient	200 ppm/Cel
Terminal Finish	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal Shape	FLAT
Tolerance	5 %
Working Voltage	100 V
