JXO-7 24.000MHZ

Name: JXO-7 24.000MHZ
Brand: KINSEKI
SKU: 400053184-0000-0000-0000

JXO-7 24.000MHZ - KINSEKI の商品詳細ページです。

２営業日以内に回答いたします

JXO-7 24.000MHZ の詳細情報

型番	JXO-7 24.000MHZ
メーカー	KINSEKI
Fall Time-Max	15 ns
Frequency Adjustment-Mechanical	NO
Frequency Stability	100 %
Manufacturer Series	JXO
Mounting Feature	THROUGH HOLE MOUNT
Number of Terminals	3
Operating Frequency-Max	70 MHz
Operating Frequency-Min	20.1 MHz
Operating Frequency-Nom	24 MHz
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-10 Cel
Oscillator Type	CMOS/LSTTL
Output Load	10 LS TTL, 15 pF
Package Body Material	METAL
Package Equivalence Code	SIP3,.1
Physical Dimension	11mm x 5mm x 3.6mm
Power Supplies	5 V
Qualification Status	Not Qualified
Rise Time-Max	15 ms
Sub Category	Other Oscillators
Supply Current-Max	25 mA
Supply Voltage-Nom	5 V
Symmetry-Max	60/40 %
