L-934SGD データシート

Name: L-934SGD
Brand: KINGBRIGHT
SKU: 220100123-0000-0000-0000

L-934SGD - KINGBRIGHT の商品詳細ページです。

２営業日以内に回答いたします

L-934SGD の詳細情報

型番	L-934SGD
メーカー	KINGBRIGHT
データシート
Additional Feature	HIGH RELIABILITY
Color	SUPER BRIGHT GREEN
Color@wavelength	Green
Configuration	SINGLE
Forward Current-Max	0.011 A
Forward Current-Max (A)	0.0115
Forward Voltage-Max	2.5 V
JESD-609 Code	e1
Lens Type	DIFFUSED GREEN
Luminous Intensity-Min (cd)	60
Luminous Intensity-Nom	20 mcd
Luminous Intensity-Nom (mcd)	20.0
Mounting Feature	RADIAL MOUNT
Number of Functions	1
Number of Terminals	2
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	70
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Optoelectronic Device Type	SINGLE COLOR LED
Overall Height	4.6 mm
Overall Height (mm)	4.6
Packing Method	BULK
Peak Wavelength	565 nm
Peak Wavelength (nm)	565
Reverse Voltage-Max	5 V
Reverse Voltage-Max (V)	5
Shape	ROUND
Size	3 mm
Size (mm)	3
Sub Category	Visible LEDs
T-code	T-1
Terminal Finish	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal Pitch	2.54 mm
Terminal Pitch (mm)	2.54
Viewing Angle	60 deg
Viewing Angle (deg)	60
