L-130WCP/2EGW データシート

Name: L-130WCP/2EGW
Brand: KINGBRIGHT
SKU: 220099399-0000-0000-0000

L-130WCP/2EGW - KINGBRIGHT の商品詳細ページです。

２営業日以内に回答いたします

L-130WCP/2EGW の詳細情報

型番	L-130WCP/2EGW
メーカー	KINGBRIGHT
データシート
Additional Feature	HIGH RELIABILITY
Color	HIGH EFFICIENCY RED/GREEN
Color@wavelength	Green/Orange
Configuration	COMMON CATHODE, 2 ELEMENTS
Forward Current-Max	0.03 A
Forward Current-Max (A)	0.03
Forward Voltage-Max	2.5 V
Lens Type	DIFFUSED WHITE
Luminous Intensity-Min	0.008 cd
Luminous Intensity-Nom	30.0/25.0 mcd
Luminous Intensity-Nom (mcd)	30.0/25.0
Mounting Feature	RADIAL MOUNT
Number of Functions	2
Number of LEDs in Array	2
Number of Terminals	6
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Optoelectronic Device Type	DUAL COLOR LED ARRAY
Overall Height	9.65 mm
Overall Height (mm)	9.65
Packing Method	BAG; BOX
Peak Wavelength	627/565 nm
Peak Wavelength (nm)	627/565
Shape	ROUND
Size	3 mm
Size (mm)	3
T-code	T-1
Terminal Pitch	2.54 mm
Terminal Pitch (mm)	2.54
Viewing Angle	60 deg
Viewing Angle (deg)	60
