KP2012SRCPRV データシート

Name: KP2012SRCPRV
Brand: KINGBRIGHT
SKU: 210000952-0000-0000-0000

KP2012SRCPRV - KINGBRIGHT の商品詳細ページです。

２営業日以内に回答いたします

KP2012SRCPRV の詳細情報

型番	KP2012SRCPRV
メーカー	KINGBRIGHT
データシート
Color	SUPER BRIGHT RED
Configuration	SINGLE
Forward Current-Max	0.03 A
Forward Current-Max (A)	0.03
Lens Type	WATER CLEAR
Luminous Intensity-Nom	100.0 mcd
Luminous Intensity-Nom (mcd)	100.0
Mounting Feature	SURFACE MOUNT
Number of Functions	1
Number of Terminals	2
Operating Temperature-Max	85 Cel
Operating Temperature-Max (Cel)	85
Operating Temperature-Min	-40 Cel
Operating Temperature-Min (Cel)	-40
Optoelectronic Device Type	SINGLE COLOR LED
Overall Height	1.1 mm
Overall Height (mm)	1.1
Packing Method	BULK
Peak Wavelength	660 nm
Peak Wavelength (nm)	660
Shape	RECTANGULAR
Size	1.3 mm
Size (mm)	1.3
Terminal Pitch	2.35 mm
Terminal Pitch (mm)	2.35
Viewing Angle	120 deg
Viewing Angle (deg)	120

会社名称	Kingbright Elec. Co., Ltd.
設立	1980
所在地	3F., No.317-1, Sec. 2, Zhongshan Rd., Zhonghe Dist., New Taipei City 235, Taiwan (R.O.C.)
URL	http://www.kingbright.com/
