ICC05-008-360T-F

Name: ICC05-008-360T-F
Brand: KEL
SKU: 190007615-0000-0000-0000

ICC05-008-360T-F - KEL の商品詳細ページです。

２営業日以内に回答いたします

ICC05-008-360T-F の詳細情報

型番	ICC05-008-360T-F
メーカー	KEL
Additional Feature	STANDARD: UL 94V-0, LOW PROFILE
Body Breadth	0.4 inch
Body Depth	0.2 inch
Body Length	0.4 inch
Contact Finish - Mating	PURE TIN OVER NICKEL
Contact Finish - Termination	Tin (Sn) - with Nickel (Ni) barrier
Contact Material	COPPER ALLOY
Contact Style	LEAF
Current Rating	1 A
Device Socket Type	IC SOCKET
Device Type Used On	DIP8
Housing Material	POLYBUTYLENE TEREPHTHALATE
Insulation Resistance	5000000000 ohm
JESD-609 Code	e3
Mating Contact Pitch	0.1 inch
Mounting Style	STRAIGHT
Number of Contacts	8
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-20 Cel
PCB Contact Pattern	RECTANGULAR
PCB Contact Row Spacing	0.3 mm
Terminal Pitch	2.54 mm
Termination Type	SOLDER
