DJ34-040L-F

Name: DJ34-040L-F
Brand: KEL
SKU: 140201504-0000-0000-0000

DJ34-040L-F - KEL の商品詳細ページです。

２営業日以内に回答いたします

DJ34-040L-F の詳細情報

型番	DJ34-040L-F
メーカー	KEL
Body Breadth	0.248 inch
Body Depth	0.413 inch
Body Length	1.358 inch
Body/Shell Style	PLUG
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	AU ON NI
Contact Finish - Termination	GOLD OVER NICKEL
Contact Gender	MALE
Contact Material	PHOSPHOR BRONZE
Contact Pattern	RECTANGULAR
Contact Resistance	40 mohm
Contact Style	IDC
Dielectric Withstanding Voltage	300VAC V
Insulation Resistance	1000000000 ohm
Insulator Color	BLACK
Insulator Material	LIQUID CRYSTAL POLYMER
Manufacturer Series	DJ3
Mating Contact Pitch	0.039 inch
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	1
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
PCB Contact Pattern	RECTANGULAR
Plating Thickness	4u inch
Rated Current (Signal)	0.5 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Pitch	.508 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	40
