6230-016-601

Name: 6230-016-601
Brand: KEL
SKU: 70174547-0000-0000-0000

6230-016-601 - KEL の商品詳細ページです。

２営業日以内に回答いたします

6230-016-601 の詳細情報

型番	6230-016-601
メーカー	KEL
Additional Feature	NONE
Body Depth	0.594 inch
Body Length	1.088 inch
Body/Shell Style	PLUG
Connector Type	BOARD CONNECTOR
Contact Design	PREASSEM CONN
Contact Finish - Mating	AU ON NI
Contact Gender	FEMALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Resistance	16 mohm
Contact Style	SQ PIN-SKT
Dielectric Withstanding Voltage	800VAC V
Insulation Resistance	1000000000 ohm
Insulator Material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Manufacturer Series	6230
Mating Contact Pitch	0.1 inch
Mating Contact Row Spacing	0.1 inch
Number of Rows Loaded	2
Polarization Key	CENTER
Rated Current (Signal)	1 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Total Number of Contacts	16
Wire Size-Max	28 AWG
Wire Size-Min	28 AWG
