1168-020-009 データシート

Name: 1168-020-009
Brand: KEL
SKU: 20342788-0000-0000-0000

1168-020-009 - KEL の商品詳細ページです。

２営業日以内に回答いたします

1168-020-009 の詳細情報

型番	1168-020-009
メーカー	KEL
データシート
Additional Feature	NONE
Body Breadth	0.394 inch
Body Depth	0.63 inch
Body Length	2.402 inch
Connector Type	CARD EDGE CONNECTOR
Contact Design	PREASSEM CONN
Contact Finish - Mating	AU ON NI
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Resistance	16 mohm
Contact Style	SINGLE PRONG
Dielectric Withstanding Voltage	1600VAC V
Insertion Force-Max	2.4464 N
Insulation Resistance	5000000000 ohm
Insulator Material	GLASS FILLED POLYCARBONATE
Manufacturer Series	1168
Mating Contact Pitch	0.156 inch
Mounting Type	PANEL
Number of Rows Loaded	2
Rated Current (Signal)	2 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Termination Type	SOLDER LUG
Total Number of Contacts	20
Withdrawl Force-Min	.278 N
