U10A6CI

Name: U10A6CI
Brand: KEC
SKU: 310107024-0000-0000-0000

U10A6CI - KEC の商品詳細ページです。

２営業日以内に回答いたします

U10A6CI の詳細情報

型番	U10A6CI
メーカー	KEC
Additional Feature	LOW POWER LOSS
Application	EFFICIENCY
Case Connection	ISOLATED
Configuration	COMMON CATHODE, 2 ELEMENTS
Diode Element Material	SILICON
Diode Type	RECTIFIER DIODE
Forward Voltage-Max (VF)	1.7 V
JEDEC-95 Code	TO-220AB
JESD-30 Code	R-PSFM-T2
Non-rep Pk Forward Current-Max	100 A
Number of Elements	1
Number of Phases	1
Number of Terminals	2
Operating Temperature-Max	150 Cel
Output Current-Max	5 A
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	FLANGE MOUNT Meter
Rep Pk Reverse Voltage-Max	600 V
Reverse Current-Max	30 uA
Reverse Recovery Time-Max	0.035 us
Surface Mount	NO
Terminal Form	THROUGH-HOLE
Terminal Position	SINGLE
