KTC4373

Name: KTC4373
Brand: KEC
SKU: 210097711-0000-0000-0000

KTC4373 - KEC の商品詳細ページです。

２営業日以内に回答いたします

KTC4373 の詳細情報

型番	KTC4373
メーカー	KEC
Additional Feature	LOW NOISE
Case Connection	COLLECTOR
Collector Current-Max (IC)	0.8 A
Collector-emitter Voltage-Max	120 V
Configuration	SINGLE
DC Current Gain-Min (hFE)	80
JESD-30 Code	R-PSSO-F3
JESD-609 Code	e3
Moisture Sensitivity Level	1
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Polarity/Channel Type	NPN
Power Dissipation-Max (Abs)	0.5 W
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	YES
Terminal Finish	Matte Tin (Sn)
Terminal Form	FLAT
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	10
Transistor Element Material	SILICON
Transition Frequency-Nom (fT)	120 MHz
