KTA1266-Y

Name: KTA1266-Y
Brand: KEC
SKU: 210041474-0000-0000-0000

KTA1266-Y - KEC の商品詳細ページです。

２営業日以内に回答いたします

KTA1266-Y の詳細情報

型番	KTA1266-Y
メーカー	KEC
Additional Feature	LOW NOISE
Collector Current-Max (IC)	0.15 A
Collector-emitter Voltage-Max	50 V
Configuration	SINGLE
DC Current Gain-Min (hFE)	120
JEDEC-95 Code	TO-92
JESD-30 Code	O-PBCY-T3
JESD-609 Code	e0
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	ROUND
Package Style	CYLINDRICAL Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Polarity/Channel Type	PNP
Power Dissipation-Max (Abs)	0.625 W
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	NO
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Transistor Application	SWITCHING
Transistor Element Material	SILICON
Transition Frequency-Nom (fT)	80 MHz
