KIA431F-RTF/P

Name: KIA431F-RTF/P
Brand: KEC
SKU: 210099154-0000-0000-0000

KIA431F-RTF/P - KEC の商品詳細ページです。

２営業日以内に回答いたします

KIA431F-RTF/P の詳細情報

型番	KIA431F-RTF/P
メーカー	KEC
Analog IC - Other Type	THREE TERMINAL VOLTAGE REFERENCE
JESD-30 Code	R-PSSO-F3
Length	4.7 mm
Number of Functions	1
Number of Outputs	1
Number of Terminals	3
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Voltage-Max	2.55 V
Output Voltage-Min	2.44 V
Output Voltage-Nom	2.495 V
Package Body Material	PLASTIC/EPOXY
Package Code	LSOF
Package Equivalence Code	TO-243
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Screening Level	AEC-Q100
Seated Height-Max	0.6 mm
Supply Voltage-Max (Vsup)	2.55 V
Supply Voltage-Min (Vsup)	2.44 V
Supply Voltage-Nom (Vsup)	2.495 V
Surface Mount	YES
Technology	BIPOLAR
Temp Coef of Voltage-Max	888 ppm/Cel
Temperature Grade	INDUSTRIAL
Terminal Form	FLAT
Terminal Pitch	1.5 mm
Terminal Position	SINGLE
Trim/Adjustable Output	NO V
Voltage Tolerance-Max	2.2 %
Width	2.5 mm
