UB-M5BR-S14-4S(LF)(SN) データシート

Name: UB-M5BR-S14-4S(LF)(SN)
Brand: JST
SKU: 310089434-0000-0000-0000

UB-M5BR-S14-4S(LF)(SN) - JST の商品詳細ページです。

229時間25分後以内に見積もり依頼を頂ければ、
05月08日(水) 9:00 までに見積もり回答いたします。

検討リストに追加する

UB-M5BR-S14-4S(LF)(SN) の詳細情報

型番	UB-M5BR-S14-4S(LF)(SN)
メーカー	JST
データシート
Board Mounting Option	SOLDER HOLDING FLANGE
Body Breadth	0.173 inch
Body Depth	0.335 inch
Body Length	0.287 inch
Body/Shell Style	RECEPTACLE
Connector Type	USB CONNECTOR
Contact Finish - Mating	GOLD OVER NICKEL
Contact Finish - Termination	Gold (Au) - with Nickel (Ni) barrier
Contact Gender	FEMALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Resistance	50 mohm
Contact Style	MINI-USB2.0 B
DIN Conformance	NO
Dielectric Withstanding Voltage	100VAC V
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	1000000000 ohm
JESD-609 Code	e4
MIL Conformance	NO
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of PCB Rows	1
Number of Ports	1
Number of Rows Loaded	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	1 A
Reference Standard	UL
Shell Finish	TIN
Shell Material	COPPER ALLOY
Terminal Pitch	0.8 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	5
UL Flammability Code	94V-0
