SM06B-SHLS-TF(LF)(SN) データシート

Name: SM06B-SHLS-TF(LF)(SN)
Brand: JST
SKU: 290234395-0000-0000-0000

SM06B-SHLS-TF(LF)(SN) - JST の商品詳細ページです。

２営業日以内に回答いたします

SM06B-SHLS-TF(LF)(SN) の詳細情報

型番	SM06B-SHLS-TF(LF)(SN)
メーカー	JST
データシート
Additional Feature	SHROUDED
Body Breadth	0.069 inch
Body Depth	0.169 inch
Body Length	0.346 inch
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	TIN OVER COPPER
Contact Finish - Termination	Tin/Copper (Sn/Cu)
Contact Gender	MALE
Contact Material	PHOSPHOR BRONZE
Contact Pattern	RECTANGULAR
Contact Style	BELLOWED TYPE
DIN Conformance	NO
Filter Feature	NO
IEC Conformance	NO
Insulator Material	POLYAMIDE
JESD-609 Code	e2
MIL Conformance	NO
Mating Contact Pitch	0.039 inch
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of PCB Rows	1
Number of Rows Loaded	1
Option	GENERAL PURPOSE
Terminal Pitch	1 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	6
UL Flammability Code	94V-0
