SF3F-41GF-P2.0 データシート

Name: SF3F-41GF-P2.0
Brand: JST
SKU: 290025624-0000-0000-0000

SF3F-41GF-P2.0 - JST の商品詳細ページです。

２営業日以内に回答いたします

SF3F-41GF-P2.0 の詳細情報

型番	SF3F-41GF-P2.0
メーカー	JST
データシート
Additional Feature	CONTACT FINISH: GOLD OVER NICKEL
Approvals	CSA; UL; VDE V
Assembly Item Name	CONTACT
Cable Entry-Max	0.11 inch
Cable Entry-Min	0.071 inch
Connector Support Type	CONNECTOR ACCESSORY
Contact Design	STRIP
Contact Gender	FEMALE
Contact Resistance	10 mohm
Contact Style	BELLOWED CONTACT
DIN Conformance	NO
Finish Thickness	15
IEC Conformance	NO
MIL Conformance	NO
Material	COPPER ALLOY
Mounting Style	STRAIGHT
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
Rated Current	14 A
Rated Voltage (AC)	600 V
Rated Voltage (DC)	600 V
Terminal Length	0.209 inch
Terminal Type	CRIMP
Wire Size-Max	16 AWG
Wire Size-Min	20 AWG
