S3B-ZR(LF)(SN) データシート

Name: S3B-ZR(LF)(SN)
Brand: JST
SKU: 290433361-0000-0000-0000

S3B-ZR(LF)(SN) - JST の商品詳細ページです。

２営業日以内に回答いたします

S3B-ZR(LF)(SN) の詳細情報

型番	S3B-ZR(LF)(SN)
メーカー	JST
データシート
Body Breadth	0.146 inch
Body Depth	0.236 inch
Body Length	0.236 inch
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	TIN
Contact Finish - Termination	Tin (Sn) over Copper (Cu)
Contact Gender	MALE
Contact Material	PHOSPHOR BRONZE
Contact Pattern	RECTANGULAR
Contact Style	RND PIN-SKT
Dielectric Withstanding Voltage	500VAC V
Filter Feature	NO
Insulation Resistance	500000000 ohm
Mating Contact Pitch	0.059 inch
Mixed Contacts	NO
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD
Number Of Connectors	ONE
Number of Rows Loaded	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-25 Cel
Option	GENERAL PURPOSE
Rated Current (Signal)	1 A
Reference Standard	UL, CSA
Terminal Length	0.106 inch
Terminal Pitch	1.5 mm
Termination Type	SOLDER
Total Number of Contacts	3
UL Flammability Code	94V-0
Wire Size-Max	26 AWG
Wire Size-Min	32 AWG
