PARP10V データシート

Name: PARP10V
Brand: JST
SKU: 260224421-0000-0000-0000

PARP10V - JST の商品詳細ページです。

２営業日以内に回答いたします

PARP10V の詳細情報

型番	PARP10V
メーカー	JST
データシート
Additional Feature	COMPATIBLE CONTACTS: SPA-001T-P0.5
Body Breadth	0.283 inch
Body Depth	0.449 inch
Body Length	0.866 inch
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	NOT SPECIFIED
Contact Gender	FEMALE
Contact Material	NOT SPECIFIED
Contact Pattern	RECTANGULAR
Contact Resistance	20 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	800VAC V
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	1000000000 ohm
Insulator Color	WHITE
Insulator Material	POLYAMIDE66
MIL Conformance	NO
Mating Contact Pitch	0.079 inch
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Type	CABLE
Number Of Connectors	ONE
Number of Rows Loaded	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-25 Cel
Option	GENERAL PURPOSE
Rated Current (Signal)	3 A
Reference Standard	UL
Termination Type	CRIMP
Total Number of Contacts	10
UL Flammability Code	94V-0
