BM04B-SRSS-TB データシート

Name: BM04B-SRSS-TB
Brand: JST
SKU: 120064859-0000-0000-0000

BM04B-SRSS-TB - JST の商品詳細ページです。

２営業日以内に回答いたします

BM04B-SRSS-TB の詳細情報

型番	BM04B-SRSS-TB
メーカー	JST
データシート
Additional Feature	LOW PROFILE; TOP ENTRY
Body Breadth	0.141 inch
Body Depth	0.168 inch
Body Length	0.236 inch
Body/Shell Style	RECEPTACLE
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	SN ON CU
Contact Finish - Termination	TIN OVER COPPER
Contact Gender	MALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Resistance	40 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	500VAC V
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	100000000 ohm
Insulator Color	NATURAL
Insulator Material	POLYAMIDE
JESD-609 Code	e2
MIL Conformance	NO
Manufacturer Series	BM04B
Mating Contact Pitch	0.039 inch
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	1
Number of Rows Loaded	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-25 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	0.7 A
Reference Standard	UL, CSA
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Pitch	.9906 mm
Termination Type	SURFACE MOUNT
Total Number of Contacts	4
UL Flammability Code	94V-0
