NJU6533FG1

Name: NJU6533FG1
Brand: JRC
SKU: 240086077-0000-0000-0000

NJU6533FG1 - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJU6533FG1 の詳細情報

型番	NJU6533FG1
メーカー	JRC
Additional Feature	ALSO OPERATES AT 5V SUPPLY
Data Input Mode	SERIAL
Display Mode	DOT MATRIX
Interface IC Type	LIQUID CRYSTAL DISPLAY DRIVER
JESD-30 Code	S-PQFP-G64
JESD-609 Code	e6
Length	14 mm
Multiplexed Display Capability	YES
Number of Functions	1
Number of Segments	36
Number of Terminals	64
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	LQFP
Package Shape	SQUARE
Package Style	FLATPACK, LOW PROFILE Meter
Qualification Status	Not Qualified
Seated Height-Max	1.7 mm
Supply Voltage-Max	3.6 V
Supply Voltage-Min	2.4 V
Supply Voltage-Nom	3 V
Supply Voltage1-Max	5.5 V
Supply Voltage1-Min	2.4 V
Supply Voltage1-Nom	3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN BISMUTH
Terminal Form	GULL WING
Terminal Pitch	0.8 mm
Terminal Position	QUAD
Width	14 mm
fmax-Min	2 MHz
