NJM4200D の詳細情報

型番	NJM4200D
メーカー	JRC
データシート
Analog IC - Other Type	ANALOG MULTIPLIER OR DIVIDER
Bandwidth-Nom	4 kHz
JESD-30 Code	R-PDIP-T8
JESD-609 Code	e0
Length	8.8 mm
Moisture Sensitivity Level	2
Neg Supply Voltage-Nom (Vsup)	-15 V
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-20 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP8,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	-15 V
Qualification Status	Not Qualified
Seated Height-Max	4.7 mm
Sub Category	Analog Computational Functions
Supply Current-Max (Isup)	4 mA
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	COMMERCIAL EXTENDED
Terminal Finish	TIN LEAD
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Width	7.62 mm
