NJM4151M データシート

Name: NJM4151M
Brand: JRC
SKU: 240008793-0000-0000-0000

NJM4151M - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJM4151M の詳細情報

型番	NJM4151M
メーカー	JRC
データシート
Converter Type	VOLTAGE TO FREQUENCY CONVERTER
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e6
Length	5 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	8
Operating Frequency-Max	0.01 MHz
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.3
Package Shape	SQUARE
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Positive Input Voltage-Max	10 V
Power Supplies	15 V
Qualification Status	Not Qualified
Seated Height-Max	2 mm
Sub Category	Analog Special Function Converters
Supply Current-Max	7.5 mA
Supply Voltage-Max	22 V
Supply Voltage-Min	8 V
Supply Voltage-Nom	15 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	COMMERCIAL EXTENDED
Terminal Finish	TIN BISMUTH
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
Width	5 mm
