NJM4151D データシート

Name: NJM4151D
Brand: JRC
SKU: 240000046-0000-0000-0000

NJM4151D - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJM4151D の詳細情報

型番	NJM4151D
メーカー	JRC
データシート
Converter Type	VOLTAGE TO FREQUENCY CONVERTER
JESD-30 Code	R-PDIP-T8
JESD-609 Code	e6
Length	8.8 mm
Number of Functions	1
Number of Terminals	8
Operating Frequency-Max	0.1 MHz
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP8,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Positive Input Voltage-Max	10 V
Power Supplies	15 V
Qualification Status	Not Qualified
Seated Height-Max	4.7 mm
Sub Category	Analog Special Function Converters
Supply Current-Max	7.5 mA
Supply Voltage-Max	22 V
Supply Voltage-Min	8 V
Supply Voltage-Nom	15 V
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN BISMUTH
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Width	7.62 mm
