NJM2902CV

Name: NJM2902CV
Brand: JRC
SKU: 240123764-0000-0000-0000

NJM2902CV - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJM2902CV の詳細情報

型番	NJM2902CV
メーカー	JRC
Amplifier Type	OPERATIONAL AMPLIFIER
Average Bias Current-Max (IIB)	0.15 uA
Common-mode Reject Ratio-Nom	100 dB
Input Offset Voltage-Max	7000 uV
JESD-30 Code	R-PDSO-G14
Length	5 mm
Number of Functions	4
Number of Terminals	14
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Seated Height-Max	1.45 mm
Slew Rate-Nom	0.6 V/us
Sub Category	Operational Amplifier
Supply Voltage Limit-Max	32 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Unity Gain BW-Nom	1300 kHz
Width	4.4 mm
