NJM2855DL1-33(TE1)

Name: NJM2855DL1-33(TE1)
Brand: JRC
SKU: 240121313-0000-0000-0000

NJM2855DL1-33(TE1) - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJM2855DL1-33(TE1) の詳細情報

型番	NJM2855DL1-33(TE1)
メーカー	JRC
Dropout Voltage1-Max	0.28 V
Dropout Voltage1-Nom	0.2 V
Input Voltage-Max	8 V
Input Voltage-Min	4.3 V
JESD-30 Code	R-PSSO-G2
Load Regulation-Max	0.132 %
Number of Functions	1
Number of Terminals	2
Output Current1-Max	1.3 A
Output Voltage1-Max	3.333 V
Output Voltage1-Min	3.267 V
Output Voltage1-Nom	3.3 V
Package Body Material	PLASTIC/EPOXY
Package Code	TO-252
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Surface Mount	YES
Technology	BIPOLAR
Terminal Form	GULL WING
Terminal Position	SINGLE
Voltage Tolerance-Max	1 %
