NJM2845DL1-05-TE1

Name: NJM2845DL1-05-TE1
Brand: JRC
SKU: 240089656-0000-0000-0000

NJM2845DL1-05-TE1 - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJM2845DL1-05-TE1 の詳細情報

型番	NJM2845DL1-05-TE1
メーカー	JRC
Dropout Voltage1-Max	0.28 V
Dropout Voltage1-Nom	0.18 V
Input Voltage-Max	11 V
Input Voltage-Min	6 V
JESD-30 Code	R-PSSO-G3
Load Regulation-Max	0.16 %
Moisture Sensitivity Level	2
Number of Functions	1
Number of Terminals	3
Output Current1-Max	1.05 A
Output Voltage1-Max	5.05 V
Output Voltage1-Min	4.95 V
Output Voltage1-Nom	5 V
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Surface Mount	YES
Technology	BIPOLAR
Terminal Form	GULL WING
Terminal Position	SINGLE
Voltage Tolerance-Max	1 %
