NJM2845DL1-05

Name: NJM2845DL1-05
Brand: JRC
SKU: 240008521-0000-0000-0000

NJM2845DL1-05 - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJM2845DL1-05 の詳細情報

型番	NJM2845DL1-05
メーカー	JRC
Dropout Voltage1-Max	0.28 V
Dropout Voltage1-Nom	0.18 V
Input Voltage-Max	11 V
Input Voltage-Min	6 V
JESD-30 Code	R-PSSO-G2
JESD-609 Code	e6
Length	6.54 mm
Load Regulation-Max	0.16 %
Moisture Sensitivity Level	2
Number of Functions	1
Number of Terminals	2
Output Current1-Max	0.8 A
Output Voltage1-Max	5.05 V
Output Voltage1-Min	4.95 V
Output Voltage1-Nom	5 V
Package Body Material	PLASTIC/EPOXY
Package Code	TO-252
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Regulator Type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	2.63 mm
Surface Mount	YES
Technology	BIPOLAR
Terminal Finish	TIN BISMUTH
Terminal Form	GULL WING
Terminal Pitch	2.28 mm
Terminal Position	SINGLE
Voltage Tolerance-Max	1 %
Width	6.04 mm
