NJM2717RB1-TE1

Name: NJM2717RB1-TE1
Brand: JRC
SKU: 240123378-0000-0000-0000

NJM2717RB1-TE1 - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJM2717RB1-TE1 の詳細情報

型番	NJM2717RB1-TE1
メーカー	JRC
Amplifier Type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB)	4.4 uA
Bias Current-Max (IIB) @25C	4.4 uA
Common-mode Reject Ratio-Nom	80 dB
Frequency Compensation	YES
Input Offset Voltage-Max	11000 uV
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e3
Length	2.9 mm
Low-Offset	NO
Moisture Sensitivity Level	1
Number of Functions	2
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	VSSOP
Package Equivalence Code	TSSOP8,.16
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH Meter
Packing Method	TAPE AND REEL
Power Supplies	2.7/12 V
Qualification Status	Not Qualified
Seated Height-Max	1 mm
Slew Rate-Nom	40 V/us
Sub Category	Operational Amplifier
Supply Current-Max	14.5 mA
Supply Voltage Limit-Max	15 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Unity Gain BW-Nom	20000 kHz
Voltage Gain-Min	1000
Width	2.8 mm
