NJM2717M(TE1) Jrc

NJM2717M(TE1) - JRC の商品詳細ページです。

1
NJM2717M(TE1)
  • NJM2717M(TE1)
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

NJM2717M(TE1) の詳細情報

  • 仕様・詳細
  • メーカー情報
型番NJM2717M(TE1)
メーカーJRC
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB) 4.4 uA
Bias Current-Max (IIB) @25C 4.4 uA
Common-mode Reject Ratio-Nom 80 dB
Frequency Compensation YES
Input Offset Voltage-Max 11000 uV
JESD-30 Code S-PDSO-G8
JESD-609 Code e3
Length 5 mm
Low-Offset NO
Moisture Sensitivity Level 1
Number of Functions 2
Number of Terminals 8
Operating Temperature-Max 85 Cel
Operating Temperature-Min -40 Cel
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP8,.25
Package Shape SQUARE
Package Style SMALL OUTLINE Meter
Packing Method TAPE AND REEL
Power Supplies 2.7/12 V
Qualification Status Not Qualified
Seated Height-Max 2 mm
Slew Rate-Nom 40 V/us
Sub Category Operational Amplifier
Supply Current-Max 14.5 mA
Supply Voltage Limit-Max 15 V
Supply Voltage-Nom (Vsup) 5 V
Surface Mount YES
Technology BIPOLAR
Temperature Grade INDUSTRIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Unity Gain BW-Nom 20000 kHz
Voltage Gain-Min 1000
Width 5 mm
