NJM2125F-TE1 データシート

Name: NJM2125F-TE1
Brand: JRC
SKU: 240000887-0000-0000-0000

NJM2125F-TE1 - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJM2125F-TE1 の詳細情報

型番	NJM2125F-TE1
メーカー	JRC
データシート
Amplifier Type	OPERATIONAL AMPLIFIER
Average Bias Current-Max (IIB)	0.25 uA
Common-mode Reject Ratio-Nom	90 dB
Input Offset Voltage-Max	7000 uV
JESD-30 Code	R-PDSO-G5
Length	2.9 mm
Number of Functions	1
Number of Terminals	5
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Qualification Status	Not Qualified
Seated Height-Max	1.3 mm
Slew Rate-Nom	1.2 V/us
Sub Category	Operational Amplifier
Supply Voltage Limit-Max	20 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Form	GULL WING
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Unity Gain BW-Nom	1200 kHz
Width	1.6 mm
