NJM2102M データシート

Name: NJM2102M
Brand: JRC
SKU: 240001405-0000-0000-0000

NJM2102M - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJM2102M の詳細情報

型番	NJM2102M
メーカー	JRC
データシート
Adjustable Threshold	NO
Analog IC - Other Type	POWER SUPPLY MANAGEMENT CIRCUIT
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e6
Length	5 mm
Moisture Sensitivity Level	1
Number of Channels	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.3
Package Shape	SQUARE
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Qualification Status	Not Qualified
Seated Height-Max	2 mm
Sub Category	Power Management Circuits
Supply Current-Max (Isup)	1 mA
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	COMMERCIAL EXTENDED
Terminal Finish	TIN BISMUTH
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Width	5 mm
