NJM12901V

Name: NJM12901V
Brand: JRC
SKU: 240051337-0000-0000-0000

NJM12901V - JRC の商品詳細ページです。

２営業日以内に回答いたします

NJM12901V の詳細情報

型番	NJM12901V
メーカー	JRC
Amplifier Type	COMPARATOR
Average Bias Current-Max (IIB)	0.2 uA
Bias Current-Max (IIB) @25C	0.2 uA
Input Offset Voltage-Max	4000 uV
JESD-30 Code	R-PDSO-G14
JESD-609 Code	e6
Length	5 mm
Number of Functions	4
Number of Terminals	14
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Type	OPEN-COLLECTOR
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Equivalence Code	TSSOP14,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Qualification Status	Not Qualified
Response Time-Nom	500 ns
Seated Height-Max	1.45 mm
Sub Category	Comparator
Supply Current-Max	1.8 mA
Supply Voltage Limit-Max	15 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN BISMUTH
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Width	4.4 mm
