PS-5SD-S4TS1-1 データシート

Name: PS-5SD-S4TS1-1
Brand: JAE
SKU: 260140000-0000-0000-0000

PS-5SD-S4TS1-1 - JAE の商品詳細ページです。

２営業日以内に回答いたします

PS-5SD-S4TS1-1 の詳細情報

型番	PS-5SD-S4TS1-1
メーカー	JAE
データシート
Body Breadth	0.157 inch
Body Depth	0.374 inch
Body Length	0.5 inch
Body/Shell Style	RECEPTACLE
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	GOLD (4) OVER NICKEL
Contact Finish - Termination	GOLD OVER NICKEL
Contact Gender	FEMALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Resistance	10 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	1400VAC V
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	3.058 N
Insulation Resistance	1000000000 ohm
Insulator Color	BLACK
Insulator Material	POLYESTER
JESD-609 Code	e4
MIL Conformance	NO
Manufacturer Series	PS
Mating Contact Pitch	0.1 inch
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	1
Number of Rows Loaded	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
Plating Thickness	4u inch
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	3 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Length	0.115 inch
Terminal Pitch	2.54 mm
Termination Type	SOLDER
Total Number of Contacts	5
UL Flammability Code	94V-0
