IL-G-4S-S3C2-SA

Name: IL-G-4S-S3C2-SA
Brand: JAE
SKU: 190057993-0000-0000-0000

IL-G-4S-S3C2-SA - JAE の商品詳細ページです。

２営業日以内に回答いたします

IL-G-4S-S3C2-SA の詳細情報

型番	IL-G-4S-S3C2-SA
メーカー	JAE
種別	IL-Gシリーズ
Body Breadth	0.236 inch
Body Depth	0.311 inch
Body Length	0.413 inch
Connector Type	BOARD CONNECTOR
Contact Gender	FEMALE
Contact Pattern	RECTANGULAR
Contact Style	SQ PIN-SKT
Dielectric Withstanding Voltage	2100VAC V
Insulation Resistance	100000000 ohm
Insulator Color	BROWN
Insulator Material	POLYAMIDE
Manufacturer Series	IL-G
Mating Contact Pitch	0.098 inch
Mounting Option 1	LOCKING
Mounting Type	CABLE
Number of Rows Loaded	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	3 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Termination Type	CRIMP
Total Number of Contacts	4
Wire Size-Max	22 AWG
Wire Size-Min	28 AWG
