IL-G-14P-S3T2-E データシート

Name: IL-G-14P-S3T2-E
Brand: JAE
SKU: 400067148-0000-0000-0000

IL-G-14P-S3T2-E - JAE の商品詳細ページです。

２営業日以内に回答いたします

IL-G-14P-S3T2-E の詳細情報

型番	IL-G-14P-S3T2-E
メーカー	JAE
種別	IL-Gシリーズ
データシート
Additional Feature	WITH LOW PROFILE
Body Breadth	0.236 inch
Body Depth	0.28 inch
Body Length	1.398 inch
Body/Shell Style	RECEPTACLE
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	SN ON NI
Contact Finish - Termination	TIN OVER NICKEL
Contact Gender	MALE
Contact Material	BRASS
Contact Pattern	RECTANGULAR
Contact Resistance	20 mohm
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	1500VAC V
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	100000000 ohm
Insulator Color	BROWN
Insulator Material	POLYAMIDE
MIL Conformance	NO
Manufacturer Series	IL-G
Mating Contact Pitch	0.098 inch
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	1
Number of Rows Loaded	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	3 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Length	0.138 inch
Terminal Pitch	2.5 mm
Termination Type	SOLDER
Total Number of Contacts	14
UL Flammability Code	94V-0
