D38999/20FC35PA

Name: D38999/20FC35PA
Brand: ITT CANON
SKU: 140202072-0000-0000-0000

D38999/20FC35PA - ITT CANON の商品詳細ページです。

２営業日以内に回答いたします

D38999/20FC35PA の詳細情報

型番	D38999/20FC35PA
メーカー	ITT CANON
Additional Feature	COMPATIBLE CONTACTS:M39029/58-360
Backshell Type	SOLID
Body/Shell Style	RECEPTACLE
Connector Type	MIL SERIES CIRCULAR CONNECTOR
Contact Finish - Mating	GOLD
Contact Finish - Termination	GOLD
Contact Gender	MALE
Contact Material	NOT SPECIFIED
Contact Quantities	22
Contact Sizes	22D
Contact Style	RND PIN-SKT
Coupling Type	THREADED
DIN Conformance	NO
Degrees of Rotation	113
EMI Shielded	NO
Empty Shell	NO
Environmental Characteristics	CORROSION/ENVIRONMENT/FLUID/VIBRATION RESISTANT
Filter Feature	NO
IEC Conformance	NO
Insulator Material	POLYETHYLENE
JESD-609 Code	e4
MIL Conformance	NO
Mains Connector Rating	5A
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Type	CABLE AND PANEL
Number Of Connectors	ONE
Number of Ports	1
Operating Temperature-Max	200 Cel
Operating Temperature-Min	-65 Cel
Option	GENERAL PURPOSE
Panel Mount	NO
Polarization	A
Polarization Key	POLARIZED
Rated Current (Signal)	5 A
Shell Finish	NICKEL
Shell Material	ALUMINIUM ALLOY
Shell Size	13
Termination Type	CRIMP
Total Number of Contacts	22
Unique Insert Number	C35
Wire Size-Max	22 AWG
Wire Size-Min	28 AWG
