IS43R16800E-5TL

Name: IS43R16800E-5TL
Brand: ISSI
SKU: 400065553-0000-0000-0000

IS43R16800E-5TL - ISSI の商品詳細ページです。

２営業日以内に回答いたします

IS43R16800E-5TL の詳細情報

型番	IS43R16800E-5TL
メーカー	ISSI
Access Mode	FOUR BANK PAGE BURST
Access Time-Max	0.7 ns
Additional Feature	AUTO/SELF REFRESH
Clock Frequency-Max (fCLK)	200 MHz
I/O Type	COMMON
Interleaved Burst Length	2,4,8
JESD-30 Code	R-PDSO-G66
Length	22.22 mm
Memory Density	134217728 bit
Memory IC Type	DDR1 DRAM
Memory Width	16
Number of Functions	1
Number of Ports	1
Number of Terminals	66
Number of Words	8388608 words
Number of Words Code	8M
Operating Mode	SYNCHRONOUS
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-40 Cel
Organization	8MX16
Output Characteristics	3-STATE
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP66,.46
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Power Supplies	2.5 V
Qualification Status	Not Qualified
Refresh Cycles	4096
Seated Height-Max	1.2 mm
Self Refresh	YES
Sequential Burst Length	2,4,8
Standby Current-Max	0.003 Amp
Sub Category	DRAMs
Supply Current-Max	0.24 mA
Supply Voltage-Max (Vsup)	2.7 V
Supply Voltage-Min (Vsup)	2.3 V
Supply Voltage-Nom (Vsup)	2.5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Form	GULL WING
Terminal Pitch	0.635 mm
Terminal Position	DUAL
Width	10.16 mm
