11DQ03

Name: 11DQ03
Brand: IR
SKU: 20498553-0000-0000-0000

11DQ03 - IR の商品詳細ページです。

２営業日以内に回答いたします

11DQ03 の詳細情報

型番	11DQ03
メーカー	IR
Additional Feature	FREE WHEELING DIODE, HIGH RELIABILITY
Application	EFFICIENCY
Breakdown Voltage-Min	30 V
Case Connection	ISOLATED
Configuration	SINGLE
Diode Element Material	SILICON
Diode Type	RECTIFIER DIODE
Forward Voltage-Max (VF)	0.45 V
JEDEC-95 Code	DO-41
JESD-30 Code	O-PALF-W2
JESD-609 Code	e0
Moisture Sensitivity Level	1
Non-rep Pk Forward Current-Max	35 A
Number of Elements	1
Number of Phases	1
Number of Terminals	2
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	1 A
Package Body Material	PLASTIC/EPOXY
Package Shape	ROUND
Package Style	LONG FORM Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Rep Pk Reverse Voltage-Max	30 V
Reverse Current-Max	1000 uA
Reverse Test Voltage	30 V
Sub Category	Rectifier Diodes
Surface Mount	NO
Technology	SCHOTTKY
Terminal Finish	TIN LEAD
Terminal Form	WIRE
Terminal Position	AXIAL
Time@Peak Reflow Temperature-Max (s)	40
