IRFF9220

Name: IRFF9220
Brand: INTERSIL
SKU: 190005338-0000-0000-0000

IRFF9220 - INTERSIL の商品詳細ページです。

２営業日以内に回答いたします

IRFF9220 の詳細情報

型番	IRFF9220
メーカー	INTERSIL
Avalanche Energy Rating (Eas)	180 mJ
Case Connection	DRAIN
Configuration	SINGLE
DS Breakdown Voltage-Min	200 V
Drain Current-Max (Abs) (ID)	2.5 A
Drain Current-Max (ID)	2.5 A
Drain-source On Resistance-Max	1.5 ohm
FET Technology	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 Code	TO-205
JESD-30 Code	O-MBCY-W3
JESD-609 Code	e0
Number of Elements	1
Number of Terminals	3
Operating Mode	ENHANCEMENT MODE
Operating Temperature-Max	150 Cel
Package Body Material	METAL
Package Shape	ROUND
Package Style	CYLINDRICAL Meter
Peak Reflow Temperature (Cel)	260
Polarity/Channel Type	P-CHANNEL
Power Dissipation Ambient-Max	20 W
Power Dissipation-Max (Abs)	20 W
Pulsed Drain Current-Max (IDM)	10 A
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	NO
Terminal Finish	TIN LEAD
Terminal Form	WIRE
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	40
Transistor Application	SWITCHING
Transistor Element Material	SILICON
Turn-off Time-Max (toff)	90 ns
Turn-on Time-Max (ton)	90 ns
