IH5018CPA
1
-
- 個
２営業日以内に回答いたします
IH5018CPA の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | IH5018CPA |
|---|---|
| メーカー | INTERSIL |
| Analog IC - Other Type | SPDT |
| JESD-30 Code | R-PDIP-T8 |
| JESD-609 Code | e0 |
| Length | 9.585 mm |
| Normal Position | NC V |
| Number of Channels | 1 |
| Number of Functions | 1 |
| Number of Terminals | 8 |
| On-state Resistance-Max (Ron) | 150 ohm |
| Operating Temperature-Max | 70 Cel |
| Operating Temperature-Min | 0 Cel |
| Output | SEPARATE OUTPUT V |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | DIP |
| Package Equivalence Code | DIP8,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE Meter |
| Qualification Status | Not Qualified |
| Seated Height-Max | 5.33 mm |
| Sub Category | Multiplexer or Switches |
| Supply Voltage-Nom (Vsup) | 4.5 V |
| Surface Mount | NO |
| Switch-off Time-Max | 500 ns |
| Switch-on Time-Max | 500 ns |
| Switching | MAKE-BEFORE-BREAK V |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | TIN LEAD |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Width | 7.62 mm |
| 会社名称 | Intersil Americas LLC |
|---|---|
| 設立 | 1967 |
| 所在地 | 1001 Murphy Ranch Road Milpitas, CA 95035 USA |
| URL | http://www.intersil.com/ |
