ICL7650SCPA-1 Intersil

ICL7650SCPA-1 - INTERSIL の商品詳細ページです。

1
ICL7650SCPA-1
  • ICL7650SCPA-1
  • ICL7650SCPA-1
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

ICL7650SCPA-1 の詳細情報

  • 仕様・詳細
  • メーカー情報
型番ICL7650SCPA-1
メーカーINTERSIL
Amplifier Type OPERATIONAL AMPLIFIER
Architecture CHOPPER-STAB
Average Bias Current-Max (IIB) 2.0E-5 uA
Bias Current-Max (IIB) @25C 1.0E-5 uA
Common-mode Reject Ratio-Min 120 dB
Common-mode Reject Ratio-Nom 120 dB
Frequency Compensation YES
Input Offset Voltage-Max 8 uV
JESD-30 Code R-PDIP-T8
JESD-609 Code e0
Length 9.535 mm
Low-Bias YES
Low-Offset YES
Micropower NO
Neg Supply Voltage Limit-Max -9 V
Neg Supply Voltage-Nom (Vsup) -5 V
Number of Functions 1
Number of Terminals 8
Operating Temperature-Max 70 Cel
Operating Temperature-Min 0 Cel
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP8,.3
Package Shape RECTANGULAR
Package Style IN-LINE Meter
Packing Method TUBE
Power NO
Power Supplies +-2.5/+-8/5/16 V
Programmable Power NO
Qualification Status Not Qualified
Seated Height-Max 5.33 mm
Slew Rate-Nom 2.5 V/us
Sub Category Operational Amplifier
Supply Current-Max 3.2 mA
Supply Voltage Limit-Max 9 V
Supply Voltage-Nom (Vsup) 5 V
Surface Mount NO
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish MATTE TIN
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Unity Gain BW-Nom 2000 kHz
Voltage Gain-Min 3162000
Wideband NO
Width 7.62 mm
会社名称Intersil Americas LLC
設立1967
所在地1001 Murphy Ranch Road Milpitas, CA 95035 USA
URLhttp://www.intersil.com/
