HA3-5002-5 データシート Intersil

HA3-5002-5 - INTERSIL の商品詳細ページです。

1

21時間46分後 以内に見積もり依頼を頂ければ、
06月04日(火) 9:00 までに見積もり回答いたします。

  • 個
この商品のお問い合わせ

HA3-5002-5 の詳細情報

  • 仕様・詳細
  • メーカー情報
型番HA3-5002-5
メーカーINTERSIL
データシートProduct_list_pdf
Amplifier Type BUFFER
Average Bias Current-Max (IIB) 10 uA
Bandwidth (3dB)-Nom 110 MHz
Bias Current-Max (IIB) @25C 7 uA
Input Offset Voltage-Max 30000 uV
JESD-30 Code R-PDIP-T8
JESD-609 Code e0
Length 9.585 mm
Neg Supply Voltage Limit-Max -22 V
Neg Supply Voltage-Nom (Vsup) -15 V
Number of Functions 1
Number of Terminals 8
Operating Temperature-Max 75 Cel
Operating Temperature-Min 0 Cel
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP8,.3
Package Shape RECTANGULAR
Package Style IN-LINE Meter
Peak Reflow Temperature (Cel) 260
Power Supplies +-12/+-15 V
Qualification Status Not Qualified
Seated Height-Max 5.33 mm
Slew Rate-Min 1 V/us
Slew Rate-Nom 1300 V/us
Sub Category Buffer Amplifier
Supply Current-Max 10 mA
Supply Voltage Limit-Max 22 V
Supply Voltage-Nom (Vsup) 12 V
Surface Mount NO
Technology BIPOLAR
Temperature Grade COMMERCIAL EXTENDED
Terminal Finish MATTE TIN
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 10
Width 7.62 mm
会社名称Intersil Americas LLC
設立1967
所在地1001 Murphy Ranch Road Milpitas, CA 95035 USA
URLhttp://www.intersil.com/

HA3-5002-5のレビュー

HA3-5002-5 のご注文について
