EL2252CN
1
-
- 個
２営業日以内に回答いたします
EL2252CN の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | EL2252CN |
|---|---|
| メーカー | INTERSIL |
| Amplifier Type | COMPARATOR |
| Average Bias Current-Max (IIB) | 17 uA |
| Bias Current-Max (IIB) @25C | 12 uA |
| Input Offset Voltage-Max | 13000 uV |
| JESD-30 Code | R-PDIP-T14 |
| JESD-609 Code | e0 |
| Length | 19.05 mm |
| Neg Supply Voltage Limit-Max | -18 V |
| Neg Supply Voltage-Nom (Vsup) | -15 V |
| Number of Functions | 2 |
| Number of Terminals | 14 |
| Operating Temperature-Max | 75 Cel |
| Operating Temperature-Min | 0 Cel |
| Output Type | TOTEM POLE |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | DIP |
| Package Equivalence Code | DIP14,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE Meter |
| Power Supplies | +-15 V |
| Qualification Status | Not Qualified |
| Response Time-Nom | 0.009 ns |
| Seated Height-Max | 4.699 mm |
| Sub Category | Comparator |
| Supply Current-Max | 20 mA |
| Supply Voltage Limit-Max | 18 V |
| Supply Voltage-Nom (Vsup) | 15 V |
| Surface Mount | NO |
| Technology | BIPOLAR |
| Temperature Grade | COMMERCIAL EXTENDED |
| Terminal Finish | TIN LEAD |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Width | 7.62 mm |
| 会社名称 | Intersil Americas LLC |
|---|---|
| 設立 | 1967 |
| 所在地 | 1001 Murphy Ranch Road Milpitas, CA 95035 USA |
| URL | http://www.intersil.com/ |
