CA3420EZ の詳細情報

  • 仕様・詳細
  • メーカー情報
型番CA3420EZ
メーカーINTERSIL
データシートProduct_list_pdf
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB) 5.0E-6 uA
Bias Current-Max (IIB) @25C 5.0E-6 uA
Common-mode Reject Ratio-Min 70 dB
Common-mode Reject Ratio-Nom 80 dB
Frequency Compensation YES
Input Offset Voltage-Max 10000 uV
JESD-30 Code R-PDIP-T8
JESD-609 Code e3
Length 9.585 mm
Low-Bias YES
Low-Offset NO
Micropower NO
Neg Supply Voltage Limit-Max -11 V
Neg Supply Voltage-Nom (Vsup) -10 V
Number of Functions 1
Number of Terminals 8
Operating Temperature-Max 125 Cel
Operating Temperature-Min -55 Cel
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP8,.3
Package Shape RECTANGULAR
Package Style IN-LINE Meter
Power NO
Power Supplies +-10 V
Programmable Power NO
Qualification Status Not Qualified
Seated Height-Max 5.33 mm
Slew Rate-Nom 0.5 V/us
Sub Category Operational Amplifier
Supply Current-Max 1 mA
Supply Voltage Limit-Max 11 V
Supply Voltage-Nom (Vsup) 10 V
Surface Mount NO
Technology BIMOS
Temperature Grade MILITARY
Terminal Finish MATTE TIN
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Unity Gain BW-Nom 500 kHz
Voltage Gain-Min 10000
Wideband NO
Width 7.62 mm
