CA3083
データシート
1
-
- 個
２営業日以内に回答いたします
CA3083 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | CA3083 |
|---|---|
| メーカー | INTERSIL |
| データシート |  |
| Collector Current-Max (IC) | 0.1 A |
| Collector-emitter Voltage-Max | 15 V |
| Configuration | SEPARATE, 5 ELEMENTS |
| DC Current Gain-Min (hFE) | 40 |
| Highest Frequency Band | VERY HIGH FREQUENCY BAND |
| JEDEC-95 Code | MO-001AC |
| JESD-30 Code | R-GDIP-T16 |
| JESD-609 Code | e0 |
| Moisture Sensitivity Level | 1 |
| Number of Elements | 5 |
| Number of Terminals | 16 |
| Operating Temperature-Max | 125 Cel |
| Operating Temperature-Min | -55 Cel |
| Package Body Material | CERAMIC, GLASS-SEALED |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE Meter |
| Peak Reflow Temperature (Cel) | 240 |
| Polarity/Channel Type | NPN |
| Power Dissipation-Max (Abs) | 0.5 W |
| Qualification Status | Not Qualified |
| Sub Category | Other Transistors |
| Surface Mount | NO |
| Terminal Finish | MATTE TIN |
| Terminal Form | GULL WING |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 40 |
| Transistor Application | SWITCHING |
| Transistor Element Material | SILICON |
| Transition Frequency-Nom (fT) | 450 MHz |
| VCEsat-Max | 0.7 V |
| 会社名称 | Intersil Americas LLC |
|---|---|
| 設立 | 1967 |
| 所在地 | 1001 Murphy Ranch Road Milpitas, CA 95035 USA |
| URL | http://www.intersil.com/ |
