N87C251SB16 Intel

N87C251SB16 - INTEL の商品詳細ページです。

1
N87C251SB16
  • N87C251SB16
  • N87C251SB16
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

N87C251SB16 の詳細情報

  • 仕様・詳細
  • メーカー情報
型番N87C251SB16
メーカーINTEL
ADC Channels NO
Address Bus Width 16
Bit Size 8
CPU Family 80251
Clock Frequency-Max 16 MHz
DAC Channels NO
DMA Channels NO
External Data Bus Width 8
JESD-30 Code S-PQCC-J44
Length 16.5862 mm
Number of I/O Lines 32
Number of Terminals 44
Operating Temperature-Max 70 Cel
Operating Temperature-Min 0 Cel
PWM Channels YES
Package Body Material PLASTIC/EPOXY
Package Code QCCJ
Package Equivalence Code LDCC44,.7SQ
Package Shape SQUARE
Package Style CHIP CARRIER Meter
Power Supplies 5 V
Qualification Status Not Qualified
RAM (bytes) 1024
ROM (words) 16384
ROM Programmability OTPROM
Seated Height-Max 4.57 mm
Speed 16 rpm
Sub Category Microcontrollers
Supply Current-Max 80 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 4.5 V
Supply Voltage-Nom 5 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Form J BEND
Terminal Pitch 1.27 mm
Terminal Position QUAD
Width 16.5862 mm
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
