- EY1501DI-ADJ
EY1501DI-ADJ
1
-
- 個
２営業日以内に回答いたします
EY1501DI-ADJ の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | EY1501DI-ADJ |
|---|---|
| メーカー | INTEL |
| Dropout Voltage1-Max | 0.212 V |
| JESD-30 Code | S-PDSO-N10 |
| JESD-609 Code | e3 |
| Length | 3 mm |
| Moisture Sensitivity Level | 3 |
| Number of Functions | 1 |
| Number of Terminals | 10 |
| Operating Temperature, TJ-Max | 125 Cel |
| Operating Temperature, TJ-Min | -40 Cel |
| Output Current1-Max | 1 A |
| Output Voltage1-Max | 5 V |
| Output Voltage1-Min | 0.8 V |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | HVSON |
| Package Shape | SQUARE |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Regulator Type | ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR |
| Seated Height-Max | 1 mm |
| Surface Mount | YES |
| Technology | BICMOS |
| Terminal Finish | MATTE TIN |
| Terminal Form | NO LEAD |
| Terminal Pitch | 0.5 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Width | 3 mm |
| 会社名称 | Intel Corporation |
|---|---|
| 設立 | 1989 |
| 所在地 | 2200 Mission College Blvd. Santa Clara, CA 95054-1549 USA |
| URL | http://www.intel.com/ |
EY1501DI-ADJのレビュー
