D8283
1
-
- 個
２営業日以内に回答いたします
D8283 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | D8283 |
|---|---|
| メーカー | INTEL |
| Family | 82 |
| JESD-30 Code | R-GDIP-T20 |
| JESD-609 Code | e0 |
| Length | 24.825 mm |
| Logic IC Type | BUS DRIVER |
| Number of Bits | 8 |
| Number of Functions | 1 |
| Number of Ports | 2 |
| Number of Terminals | 20 |
| Operating Temperature-Max | 70 Cel |
| Operating Temperature-Min | 0 Cel |
| Output Characteristics | 3-STATE |
| Output Polarity | INVERTED |
| Package Body Material | CERAMIC, GLASS-SEALED |
| Package Code | DIP |
| Package Equivalence Code | DIP20,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE Meter |
| Power Supplies | 5 V |
| Prop. Delay@Nom-Sup | 40 ns |
| Propagation Delay (tpd) | 40 ns |
| Qualification Status | Not Qualified |
| Seated Height-Max | 5.08 mm |
| Sub Category | FF/Latches |
| Supply Voltage-Max (Vsup) | 5.5 V |
| Supply Voltage-Min (Vsup) | 4.5 V |
| Supply Voltage-Nom (Vsup) | 5 V |
| Surface Mount | NO |
| Technology | TTL |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | TIN LEAD |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Width | 7.62 mm |
| 会社名称 | Intel Corporation |
|---|---|
| 設立 | 1989 |
| 所在地 | 2200 Mission College Blvd. Santa Clara, CA 95054-1549 USA |
| URL | http://www.intel.com/ |
D8283のレビュー
D8283 のご注文について
050-3612-7934
045-263-9989
D8283 - INTEL の商品詳細ページです。
