IRG4BC30FDPBF

Name: IRG4BC30FDPBF
Brand: INFINEON
SKU: 190110193-0000-0000-0000

IRG4BC30FDPBF - INFINEON の商品詳細ページです。

２営業日以内に回答いたします

IRG4BC30FDPBF の詳細情報

型番	IRG4BC30FDPBF
メーカー	INFINEON
Case Connection	COLLECTOR
Collector Current-Max (IC)	31 A
Collector-emitter Voltage-Max	600 V
Configuration	SINGLE WITH BUILT-IN DIODE
Gate-emitter Thr Voltage-Max	6 V
Gate-emitter Voltage-Max	20 V
JEDEC-95 Code	TO-220AB
JESD-30 Code	R-PSFM-T3
JESD-609 Code	e3
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	FLANGE MOUNT Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Polarity/Channel Type	N-CHANNEL
Power Dissipation-Max (Abs)	100 W
Qualification Status	Not Qualified
Sub Category	Insulated Gate BIP Transistors
Surface Mount	NO
Terminal Finish	MATTE TIN OVER NICKEL
Terminal Form	THROUGH-HOLE
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Transistor Application	POWER CONTROL
Transistor Element Material	SILICON
Turn-off Time-Nom (toff)	620 ns
Turn-on Time-Nom (ton)	69 ns
