BAS7002VH6327XTSA1 データシート

Name: BAS7002VH6327XTSA1
Brand: INFINEON
SKU: 120189370-0000-0000-0000

BAS7002VH6327XTSA1 - INFINEON の商品詳細ページです。

２営業日以内に回答いたします

BAS7002VH6327XTSA1 の詳細情報

型番	BAS7002VH6327XTSA1
メーカー	INFINEON
データシート
Additional Feature	TR, 7 INCH: 3000; TR, 7 INCH: 8000
Application	GENERAL PURPOSE
Breakdown Voltage-Min	70 V
Configuration	SINGLE
Diode Element Material	SILICON
Diode Type	RECTIFIER DIODE
Forward Voltage-Max (VF)	1 V
JESD-30 Code	R-PDSO-F2
JESD-609 Code	e3
Moisture Sensitivity Level	1
Non-rep Pk Forward Current-Max	0.1 A
Number of Elements	1
Number of Phases	1
Number of Terminals	2
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-55 Cel
Output Current-Max	0.07 A
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Power Dissipation-Max	0.25 W
Reference Standard	AEC-Q101
Rep Pk Reverse Voltage-Max	70 V
Reverse Current-Max	0.1 uA
Reverse Test Voltage	50 V
Sub Category	Rectifier Diodes
Surface Mount	YES
Technology	SCHOTTKY
Terminal Finish	TIN
Terminal Form	FLAT
Terminal Position	DUAL
